A 2-in-1 Interoperability Gateway and RoIP Gateway
A 2-in-1 analog Interoperability Gateway and RoIP Gateway
A 2-in-1 analog Interoperability Gateway and RoIP Gateway that makes it super easy to interconnect different radios reliably and fast.
Overview
Why Choose the IPR400 S2 RoIP Gateway?
The IPR400 S2 is a full featured, fast and flexible multi-channel VoIP radio interface with analog RoIP gateway software. It combines Voice over IP extensions for analog radio equipment and interoperability between disparate radio systems all in one.
The 4 ports of the IPR400 S2 can be linked together internally to the IPR400 S2 or with VoIP in a myriad of combinations, making the device ideal for connecting repeater sites. The gateway also features SIP connectivity for use with dispatch consoles such as the omnicore series radio dispatch solutions.
When the IPR110+ is not enough, the IPR400 S2 offers isolated 4-wire E&M interfaces, multi-casting, voice activity detection, voice compression, SELCALL & DTMF signalling, encryption and RS-232 data tunnelling.
To make configuration a breeze, the IPR400 S2 now incorporates software configurable E&M signals. Using a web browser, you can configure contact, voltage or switched (power or ground) operation for both the M (PTT) outputs and the E (Busy) inputs.
PTT over Cellular (PTToC) is supported as is Remote Control over IP.
4 Ports
Control up to four two-way radios remotely over IP link
Site Monitoring
Monitor network performance via SNMP Simple Network Management Protocol
Crossbanding
Link groups of radios, IP and VoIP channels in various combinations
2in1
Analog Interoperability Gateway and RoIP Gateway
Features
2-in-1 Interoperability & Full Multi-Channel RoIP Gateway Software
Encryption
Protect against unauthorized access & eavesdropping
Web Configuration
Easy set up, management & diagnostics over IP
Network Flexibility
Connect in more ways using SIP, multicast or unicast
Quickly Link & Re-group
Combine & connect users & agencies on demand
PTT over Cellular
Use PTToC to listen & speak over connected radios
Remote Control over IP
Link & cross-band channels remotely using the IPRLink application
Features
2-in-1 Interoperability & Full Multi-Channel RoIP Gateway Software
Encryption
Protect against unauthorized access & eavesdropping
Web Configuration
Easy set up, management & diagnostics over IP
Network Flexibility
Connect in more ways using SIP, multicast or unicast
Quickly Link & Re-group
Combine & connect users & agencies on demand
PTT over Cellular
Use PTToC to listen & speak over connected radios
Remote Control over IP
Link & cross-band channels remotely using the IPRLink application
Flyer
IPR400 S2
A 2-in-1 analog Interoperability and RoIP gateway software.
Technical Specifications
What is Included?
| Feature | |
| Number of Ports | 4 (+4 RoIP) |
| Power Supply | 12 Vdc @ 500mA |
| Detect/Generate | DTMF, Selcall |
| Input/Output | Digital: 2 in/2 out Analog: 8 in |
| Network Monitoring | SNMP |
| Web Configuration/Firmware Upgrade | Included |
| VoIP | 4 channels included |
| Real-Time Remote Control | Included |
| ESChat / PTToC | Included |
Included Feature
omnilink
Communicating with radios is easier than ever before with the Omnitronics omnilink Windows application. Included as standard with the IPR400 S2 Interoperability Gateway, it gives the ability to easily control local link groups remotely from a PC or tablet.
Video
Unboxing the IPR400 S2
Watch this video to see what’s in the box and hear about real-life applications.
Connect Smart Phones and Radios
Push To Talk over Cellular | PTToC | PoC
A remote communications app connects you with all devices in the field, allowing you to stay connected anytime and anywhere. This cloud-based service is integrated with Omnitronics IPR110+ and IPR400 S2 Gateways as standard, and also integrates into Omnitronics Radio Dispatch Systems. Keeping communication lines open, even when you are without your radio.
IPR Feature Comparison
Which Radio over IP Gateway is right for you?
Analog 4-Wire E&M Port
IPR
- Isolated opto-coupled PTT and COS outputs
- Voice Activity Detection (VAD) with silence suppression for bandwidth efficiency (received analog audio on 4W E&M)
- Isolated PTT control using relay contacts and isolated COS opto-coupler input
Software control of 4W E&M busy and PTT signal interface (contact, voltage etc.)
IPR
- Isolated opto-coupled PTT and COS outputs
- Voice Activity Detection (VAD) with silence suppression for bandwidth efficiency (received analog audio on 4W E&M)
- Isolated PTT control using relay contacts and isolated COS opto-coupler input
- Software control of 4W E&M busy and PTT signal interface (contact, voltage etc.)
Handset Port
IPR
- Compatibility of handset port with Omnitronics 960 Handsets and Consoles
IPR
Compatibility of handset port with Omnitronics 960 Handsets and Consoles
Ethernet Port
IPR
- 10/100-BaseT Ethernet radio port via US Modular connector
- Software configurable and firmware upgradeable via web interface
IPR
- 10/100-BaseT Ethernet radio port via US Modular connector
- Software configurable and firmware upgradeable via web interface
Serial Port
IPR
- Serial data pass-through
- Serial radio channel change1
- Control channel-change compatible radios with Omnitronics VoIP-based radiodispatch systems such as omnicore or 960SIP
IPR
- Serial data pass-through
- Serial radio channel change1
- Control channel-change compatible radios with Omnitronics VoIP-based radiodispatch systems such as omnicore or 960SIP
LED Indicators
IPR
- Status and diagnostic LED indicators on front panel
Multifunction LCD on front panel
IPR
Status and diagnostic LED indicators on front panel- Multifunction LCD on front panel
Tone Signalling
IPR
- CTCSS detection/generation
- DTMF/Selcall detection2
- Support for CTCSS, Selcall, and DTMF over highly compressed links
- Support for CTCSS as data to minimise bandwidth usage
- Receive and transmit EIA Tone Remote sequences
- Receive and transmit MDC1200 signalling information
- Translate MDC1200 to/from Selcall tone sequences as well as in-band tones
- Tone Signalling: Selcall, DTMF (including channel change), EIA Tone Remote, Guard Tone, MDC1200, 2-Tone Paging and CTCSS
IPR
- CTCSS detection/generation
- DTMF/Selcall detection2
- Support for CTCSS, Selcall, and DTMF over highly compressed links
- Support for CTCSS as data to minimise bandwidth usage
- Receive and transmit EIA Tone Remote sequences
Receive and transmit MDC1200 signalling informationTranslate MDC1200 to/from Selcall tone sequences as well as in-band tonesTone Signalling: Selcall, DTMF (including channel change), EIA Tone Remote, Guard Tone, MDC1200, 2-Tone Paging and CTCSS
Analog Audio Delay Modes
IPR
- Interfaces to Smartnet™ type trunking radios via audio delay
- Audio delays for busy validation
- Radio/Handset: Trunk Radio audio delay mode
IPR
- Interfaces to Smartnet™ type trunking radios via audio delay
Audio delays for busy validationRadio/Handset: Trunk Radio audio delay mode
VoIP Functionality
IPR
- Static or dynamic IP address configuration
- Multicast addressing to efficiently send audio to multiple destinations
- Multiple voice codecs for optimal data compression
- Number of concurrent active VoIP sessions: 5
- PTT via VAD on incoming VoIP
- Optional voice encryption with user configurable key
- Optional DES voice encryption technology for secure voice transmissions
- Secure communications using AES encryption3
- Jitter buffer on VoIP to consoles/IPRs/DRGs
- Optional stronger encryption (AES with a key length of 256 bits)3
- ESChat integration to extend coverage of existing radio network4
- PTT via DTMF tones
Linking radio ports with omnilink
IPR
- Static or dynamic IP address configuration
- Multicast addressing to efficiently send audio to multiple destinations
- Multiple voice codecs for optimal data compression
- Number of concurrent active VoIP sessions: 48
- PTT via VAD on incoming VoIP
- Optional voice encryption with user configurable key
- Optional DES voice encryption technology for secure voice transmissions
- Secure communications using AES encryption3
- Jitter buffer on VoIP to consoles/IPRs/DRGs
- Optional stronger encryption (AES with a key length of 256 bits)3
- ESChat integration to extend coverage of existing radio network4
PTT via DTMF tones- Linking radio ports with omnilink
SIP Functionality
IPR
- Number of incoming SIP connections supported: 12
- Accept SIP calls (from Omnitronics IPR/DRG devices and consoles such as omnicore and 960SIP)
- SIP state controls local PTT
- SIP progress tones to VoIP connections
- SIP remote status sounds, disconnect by tone and connection control via tones.
- Interoperability with hardware/software SIP phones, SIP servers, SIP PBX systems
- Terminal radio to SIP phone patching (provide a radio-to-SIP-PABX gateway)
- Connect to device via SIP Server (including authentication)
- SIP connection control from Omnitronics software (web interface, omnicore, etc.)
- SIP connection control from DTMF/SELCALL inputs on 4W E&M audio input
- Originate SIP calls
- Automatic SIP registration on startup (to SIP server/PABX)
IPR
- Number of incoming SIP connections supported: 48
- Accept SIP calls (from Omnitronics IPR/DRG devices and consoles such as omnicore and 960SIP)
SIP state controls local PTTSIP progress tones to VoIP connectionsSIP remote status sounds, disconnect by tone and connection control via tones.Interoperability with hardware/software SIP phones, SIP servers, SIP PBX systemsTerminal radio to SIP phone patching (provide a radio-to-SIP-PABX gateway)Connect to device via SIP Server (including authentication)SIP connection control from Omnitronics software (web interface, omnicore, etc.)SIP connection control from DTMF/SELCALL inputs on 4W E&M audio inputOriginate SIP callsAutomatic SIP registration on startup (to SIP server/PABX)
- DRG100 supports channel change via the CCP interface for some radios (not available in the analog version).
- IPR110+ configured for DTMF/Selcall detection.
- Available only in Australia model due to export restrictions (other countries may apply for export permit — contact Omnitronics for details).
- IPR110+ standalone only; IPR400 S2 standalone and integrated with console.
Mission-Critical Radio Gateway
7+ Years of Up Time and Counting
The Omnitronics IPR400 Radio Gateway has got what it takes to be mission-critical!
Installed on a remote oil platform, this IPR has been continuously running for 2593 days, that’s 7+ Years without a fault, reset, power outage or upgrade.
When the organisation’s dispatch system was upgraded from a DX-64 to RediTALK-Flex, all the IPR400 needed was a firmware upgrade to suit the new requirements and it was straight back in service. Counting up again from 0 until we see it again in 7+ years…
